Description
Description
Designed for large open-plan spaces, the Bronte® DXK28ZRA-WF1 8.0kW Split System delivers powerful and efficient heating and cooling with advanced airflow performance. Featuring Jet Air Technology, this unit provides long-reach airflow of up to 18 metres in cooling mode, ensuring consistent comfort throughout larger areas such as living rooms, offices, and commercial spaces.
Part of the latest WF1 range, this system includes built-in Wi-Fi, allowing you to control your air conditioner remotely via a smartphone app. It also supports voice control through Google Assistant or Amazon Alexa (devices sold separately), offering added convenience and flexibility.
For improved indoor air quality, the system is equipped with Clean Air Technology and a NOVAShield™ PM2.5 filter, designed to capture and neutralise allergens, odours, bacteria, and viruses.
Key Features:
- Jet Air Technology for long-reach airflow up to 18 metres
- Designed for large spaces (7.1–9.5kW range)
- Clean Air Technology to neutralise allergens, odours, bacteria & viruses
- Built-in Wi-Fi with app control
- Voice control compatibility with Google Assistant and Amazon Alexa
- Wide range of timer and scheduling functions
Specifications:
- Power Supply: Single Phase
- Capacity: 8.0kW Cooling / 9.0kW Heating
- Type: Reverse Cycle
- Indoor Type: Wall Mounted
- Refrigerant: R32
| Indoor | DXK28ZRA-WF1 | ||||
| Outdoor | DXC28ZRA-W | ||||
| Power source (Outdoor Unit) | 1 Phase 240V 50Hz | ||||
|
*Operation data
|
Nominal Capacity (Range)
|
Cooling T1 |
kW
|
8.0 (2.3~9.5) | |
| Heating H1 | 9.0 (2.1~11.2) | ||||
| Heating H2 | 8.2 | ||||
|
Power consumption
|
Cooling T1 |
kW
|
2.22 (0.48~3.1) | ||
| Heating H1 | 2.40 (0.40~3.40) | ||||
| Maximum power consumption | kW | 3.65 | |||
|
Running current
|
Cooling T1 |
A
|
9.4 | ||
| Heating H1 | 10.2 | ||||
| Inrush current, maximum current | A | 10.2, 17.0 | |||
| EER | Cooling T1 |
|
3.6 | ||
| COP | Heating H1 | 3.75 | |||
| Sound power level (JIS C9612) | Outdoor | dB(A) | 68 | ||
|
Sound pressure level (JIS C9612)
|
Indoor |
dB(A)
|
46-43-38-25 | ||
| Outdoor | 56 | ||||
|
Energy label (GEMS 2019)
|
HOT
|
Cooling |
|
3.5 | |
| Heating | 3 | ||||
|
AVERAGE
|
Cooling | 3.5 | |||
| Heating | 2.5 | ||||
|
COLD
|
Cooling | 3.5 | |||
| Heating | 2 | ||||
|
External dimensions (HxWxD)
|
Indoor |
mm
|
339x1197x262 | ||
| Outdoor | 750×880(+88)x340 | ||||
|
Net weight
|
Indoor |
kg
|
15.5 | ||
| Outdoor | 58 | ||||
|
Airflow
|
Indoor (Cooling) |
l/s
|
383-345-300-182 | ||
| Indoor (Heating) | 450-363-315-234 | ||||
|
Refrigerant (Type, amount, pre-charge length)
|
Quantity | kg | (R32) 1.6 | ||
| Pre charged to pipe length | m | 15 | |||
|
Installation data
|
Refrigerant piping
|
Liquid line |
mm
|
Ø6.35 | |
| Gas line | Ø15.88 | ||||
| Connection method | Flare connection | ||||
| Maximum pipe (one way) length | m | 30 | |||
| Max vertical height diff. between O.U. and I.U. | m | 20 ( O.U. above I.U. ) / 20 ( O.U. below I.U. ) | |||
| Standard accessories | Allergen clear filter , NOVAShield Nano filter (PM2.5), Built-in Wi-Fi | ||||
| Optional parts | Interface kit (SC-BIKN2-E) | ||||
| Demand response (AS4755) | Yes | ||||
